什么是茶葉包裝機？常見的茶葉包裝機（袋泡茶包裝機）有哪些？
什么是茶葉包裝機？茶葉包裝機就是把茶葉自動包裝起來的機器。常見的茶葉包裝機有哪些？下面飲品茶、袋泡茶、茶葉自動包裝綜合解決方案提供商深圳市三農包裝機械有限公司給大家細說常見的茶葉包裝機有哪些。
一、新型帶線帶標袋泡茶包裝機，帶線兼標簽袋用茶包裝機，帶線帶標代用茶包裝機New take line to take the tea bag packing machine, with thread and tag with tea bag packaging machine, belt line belt scale substitute tea packing machine.帶線帶標袋泡茶包裝機Take line to take the tea bag packing machine，帶線袋泡茶包裝機
1、帶線帶標袋泡茶包裝機適合于：碎茶，茶末，茶粉，茶葉、咖啡、中藥等過濾性物品自動包裝。Suitable for: tea, tea dust, tea powder, tea, coffee, Chinese traditional medicine filterability items such as automatic packaging.
Take line to take the tea bag packing machine, with tea bag packaging machine packaging materials: filter cotton paper, cotton, labels
二、內外袋帶線帶標袋泡茶包裝機，內外袋袋泡茶包裝機，袋泡茶內外袋包裝機Line inside and outside the bag with the tea bag packing machine, inside and outside the bag of tea bag packaging machine, tea bag inside and outside the bag packaging machine
1、內外袋帶線帶標袋泡茶包裝機，內外袋袋泡茶包裝機的適用范圍：Line inside and outside the bag with the tea bag packing machine, bag tea bag packaging machine inside and outside of the scope of application:
本機適用于茶葉、藥茶、保健茶草根類等小顆粒物的內外袋一次性包裝。The machine is suitable for tea, herbal tea, health tea grassroots small particles inside and outside the bag, such as disposable packaging.
2、內外袋帶線帶標袋泡茶包裝機，內外袋袋泡茶包裝機的本機特點：Line inside and outside the bag with the tea bag packing machine, inside and outside the bag of tea bag packaging machine this machine features:
1>外封紙由步進電機控制，袋長穩定、定位準確；Paper WaiFeng consists of stepper motor control, bag length stable, accurate positioning;
2>采用PID調節溫度控制器，溫度控制得更準確；Using the PID temperature controller, temperature control more accurate;
3>采用PLC控制整機的動作，人機界面顯示，操作方便； PLC control action of the machine, the man-machine interface display, easy to operate;
4>所有可接觸物料部分為SUS304不銹鋼制作，保證產品的衛生可靠；All parts contacting material of SUS304 stainless steel, ensure health of products;
5>部分工作氣缸采用原裝進口件，保證其工作準確與穩定。Part of the working cylinder adopts imported parts, ensure the accuracy and stability.
6>本機附加裝置可完成平口剪切、日期打印、易撕口等功能。 This machine can complete the flat cutting, date printing, easy tear etc. Function.
三、內外袋帶線帶標袋泡茶包裝機，內外袋袋泡茶包裝機的主要技術參數：Line inside and outside the bag with the tea bag packing machine, bag tea bag packaging machine inside and outside the main technical parameters:
型號：SN-169 Model: SN - 169
封口形式：三邊封 計量范圍： 1-15克/包 生產能力：30-60袋/分鐘
Sealing form: three edge-sealing measuring range: 1-15 g/bag production capacity: 30 to 60 bags/min
內袋尺寸：長50-75mm；寬50-75mm 。外袋尺寸：長85-120mm；寬75-95mm。
The bag size: 50-75mm long; Wide 50-75mm. outside bag size: 85-120mm long; 75-95mm wide
標簽尺寸：25X25（長*寬） 輸入電源：220V/50HZ單相 總功率： 3.7kw
Label size: 25 x25 (length * width) input power: 220 v / 50 hz single-phase total power: 3.7 kw
整機重量：650KG 外型尺寸：1050X700X1300（長*寬*高mm）
The weight: 650 kg appearance size: 1050 x700x1300 (length * width * height in mm)
加熱器：標簽加熱棒： 110V 100W 2支 The heater: the tag element: 110 v, 100 w two
上縱封加熱管（內）110V 350W 2支 上橫封加熱管（內）110V 350W 2支
On the vertical sealing heating tube (110 v, 350 w) on the two lateral sealing heating tube (110 v, 350 w) two
下縱封加熱圈（外） 110V 350W 2支 下橫封加熱管（外） 110V 350W 2支
Under longitudinal heat sealing ring (110 v, 350 w) under the two lateral sealing heating tube (110 v, 350 w) two
三、尼龍三角袋茶葉包裝機，尼龍三角包袋泡茶包裝機，三角茶包自動包裝機Nylon triangle tea bag packaging machine, nylon package triangle tea bag packing machine, triangle tea bag packaging machine automatically
尼龍三角袋茶葉包裝機，尼龍三角包袋泡茶包裝機，三角茶包自動包裝機的特征：Nylon triangle tea bag packaging machine, nylon package triangle tea bag packing machine, automatic triangular tea bag packaging machine features:
1．通過超聲封口切斷方式，使抽出性突出且外觀形狀漂亮的茶包的生產成為可能。By ultrasonic cutting off, make out sex and beautiful shape tea production is possible.
2．包裝能力達3000袋/小時。Packaging capacity up to 3000 bags per hour.
3．用帶標簽的包裝材料可以簡單生產出帶標簽的茶包。A simple labeled packaging materials can produce tea bags with labels.
4．電子稱計量方式可以很容易在變換填充物，計量精準。Electronic scale metering can be easily in the transformation filler, measuring precision.
尼龍三角包袋泡茶包裝機該三角茶包包裝機適用于：黑茶，白茶，黃茶，藤茶，養生茶，八寶茶，養肝茶，綠茶、紅茶、花茶、咖啡、中國茶、健康茶、中藥茶、顆粒等立體三角包包裝。The triangle tea bag packaging machine is suitable for: black tea, white tea, yellow tea, rattan tea, health tea, sweet tea, nourishing the liver tea, green tea, black tea, scented tea, coffee, Chinese tea, health tea, herbal tea, particle, etc in the stereoscopic triangle bag packaging.
尼龍三角袋茶葉包裝機，尼龍三角包袋泡茶包裝機，三角茶包自動包裝機的標準規格：Nylon triangle tea bag packaging machine, nylon package triangle tea bag packing machine, automatic triangular tea bag packaging machine standard specifications:
1．生產數量計數器 2．主馬達保護裝置（循環超時） 3．馬達變壓控制 4．滑動容積超負荷保護裝置
1. Production quantity counter 2. Main motor protection device (circulation timeout) 3. The motor variable voltage control 4. Sliding volume overload protection device
5．步進馬達縱向輸送 6．檢查出標簽（檢驗出時有錯誤報警） 7．開門安全限制開關
5. Stepper motor longitudinal conveying 6. Check out the tag (tested from time to tome error alarm) 7. Open the door safety limit switches
8．包裝材料張力自動調節裝置 9．無包裝材料警報 10．超聲波負荷警報 11．靜電除去裝置
8. Packaging material tension automatic adjustment device 9. No packaging materials alarm 10. Ultrasonic load alarm 11. Electrostatic remove device
上面就是飲品茶、袋泡茶、茶葉自動包裝綜合解決方案提供商深圳市三農包裝機械有限公司給大家介紹的最常見的3種茶葉包裝機（袋泡茶包裝機）。
